北美作业代写:Abnormity wall

2018-05-10 来源: 51due教员组 类别: Paper范文

下面为大家整理一篇优秀的paper代写范文- Abnormity wall,供大家参考学习,这篇论文讨论了异形幕墙。随着建筑行业的发展和社会审美的变迁,越来越多的新建建筑采用各种标新立异的外观设计。幕墙由于其优秀的抗变形性能和外观表现力,被广泛地应用在这些高端建筑物乃至地标级建筑物上。因此,异形幕墙越来越受得建筑行业的重视。而异形结构玻璃幕墙具有很强的艺术表现力,通过异形幕墙来营造富有个性的建筑空间增强了建筑的视觉冲击力和感染力,成为幕墙建筑的代表性作品。

Abnormity wall,异形幕墙,论文代写,paper代写,北美作业代写

With the development of the construction industry and the change of social aesthetics, more and more new buildings adopt various unconventional design. The curtain wall is widely used in these high-end buildings and even landmark buildings due to its excellent anti-deformation performance and appearance. Therefore, the special-shaped curtain wall is getting more and more attention from the construction industry. The author has been engaged in the design work of special-shaped curtain wall for many years to make summary, exchange and share.

Due to the curtain wall mainly determined by its final appearance molding and plate, and shapes and plates are generally flat material, therefore easier to curtain wall made straight appearance, or mansard appearance, many buildings due to the large volume, although is in the shape of surface appearance but for detail node design, the radius of the large size can use line to approximate expression, will eventually curve into line, such as dubai gulf. Glass curtain wall as an important content in the form of modern architecture, the use of it has a very significant advantages, for example, heat preservation, decorative performance is good, its light weight, heat insulation, and can realize optical, effective sound insulation, etc. In many large public buildings in China, all can see the figure of glass curtain wall structure, it has good decoration effect and function, glass curtain wall is the organic fusion of architectural technology and art together to rational use.

In recent years, on the basis of traditional planar curtain wall, the construction of glass curtain wall is increasing, and the relevant theories and practices have been greatly developed. Special-shaped glass curtain wall structure has a strong artistic expression, through special curtain wall to create a rich individual character of architectural space to enhance the visual impact and influence, become a curtain wall construction of representative works. However, there are more technical difficulties in the construction of the glass curtain wall compared with the ordinary plane curtain wall, and the requirements of construction technology and the control of construction quality are more stringent. The glass curtain wall of the opposite-sex structure is technical and technical, and it has some difficulty. It is necessary to overcome certain construction difficulty to achieve satisfactory architectural effect.

The glass facade is built with a thin, lightweight building material that replaces the walls around the building. As the curtain wall, the material does not bear the structural load of the main body, only the enclosure effect. It is suspended or embedded in the metal frame of the building, and now the glass is used as the curtain wall. The glass curtain wall is made of aluminum alloy profile, the glass is the outer surface, the lining is lined with the composite wall of the insulation material, and the structure glue is used for sealing. Glass curtain wall glass has been used by the development of float glass, toughened glass to the absorption of heat, heat reflection glass, hollow glass, etc., the heat reflective glass is main varieties used in glass curtain wall. Structure of glass can be used for the main parts of buildings, such as doors and Windows, external walls, pervious to light roof, ceiling materials and floor, etc., is a kind of retaining structure materials of modern architecture, the palisade materials not only have the function of the specific function, and can make the colorful building. The main types of structural glass are: glass curtain wall, glass brick, special-shaped glass, imitation stone glass, etc.

The surface dust and dirt should be wiped clean before the glass installation. Heat reflective glass installation should be the coating surface toward the room, the non-coated surface towards the outside. No direct contact between glass and components. There should be no less than two elastic positioning blocks on the lower part of each glass. The width of the block is the same as that of the slot, and the length should not be less than 100mm. Both sides of the glass and the space should meet the design requirements. The rubber strips around the glass should be selected according to the specified model. The setting should be flat. The length of the rubber strip should be 1.5% ~ 2% longer than the slot in the frame, and the fracture should be left in the four corners. When the inclined plane is disconnected, it should be made into a predetermined design Angle, and the binder bond will be cemented into the slot. The gap between the glass curtain wall and the main structure should be filled with fireproof insulation material. The inner surface should be sealed with sealant, and the joints should not leak. Aluminium alloy decorative pressure plate should meet the design requirements, the surface should be flat, the color should be consistent, should not have visible deformation, corrugation and bumpy, joints should be tight. During the construction of glass curtain wall, it should be stratified to check the performance of rainwater.

Wuxi museum is located in the south square of taihu square in wuxi city. Municipal party committee, municipal government in wuxi city, the project is to determine the social culture of enterprise one of the key projects, is to reflect modern urban style, show the landscape and cultural city connotation and emphasizing science and technology culture the symbol of the city overall image. The project facade, unique design concept from "cloud-covered stone", the whole building is like a huge urban sculpture, facade lines and soft combination, comparative and bright color, give a person with strong visual impact, fully shows the city of the landscape city of wuxi characteristics and cultural connotation.

The three-space polyhedron in the middle of the building is the main part of the pavilion, which is composed of glass and single aluminum panels.

This part is the most characteristic and the most complicated part of the whole building, which is the key and difficult point in the design and construction of this project.

The composite curtain wall should be attributed to the generalized peripheral protective curtain wall system on the tectonic system, because it has no traditional so-called transverse vertical keel. The transverse main force member adopts the steel tube truss, and the concrete structure of truss is designed according to the span size, and pursues the most economical structure under the premise of satisfying the reliability. Vertical is no keel, totally stressed by structural glue. The glass is inlaid in a u-shaped slot, and the outer cover is decorated with aluminum plates.

The combination of curtain wall and wave roof is another difficulty. Because the triangle surface as the plane, if direct cut to the elevation of wave along the curve, it is a triangle convergent edge becomes a curve, the integrity of the triangle was broken, the curve on the fa? Ade is completely composed of straight line and triangular surface, on the construction effect is not acceptable. After more than with the architect scheme comparison, consultation, discussion, and finally the "curtain box of window type deal:" in the space of two surfaces, respectively, as a triangle surface waves and the interface of roof, let two materials or complete interface, and then use a "shadow plane" transitional connection, the relative penetration curve hidden in "curtain box of window", has obtained the ideal effect. In order to ensure the use of safety, a new process - aluminum base face real stone paint was used to ensure the safety. Technological process is: the substrate surface cleaning and passivation of aluminum plate to besmear to brush light metal interface agent, besmear brushs the special primer stone - spraying colorful flower hillock surface - environmental protection silicone transparent fluorocarbon paint closed processing. After processing aluminum plate surface texture and elevation of natural granite, but only about a quarter of the granite material weight, adopt the new technology, already meet the requirement of the construction effect, and to ensure the safety use.
