Assignment代写:Spatial Data Management

2018-04-04 来源: 51due教员组 类别: 更多范文

下面为大家整理一篇优秀的assignment代写范文- Spatial Data Management,供大家参考学习,这篇论文讨论了一个database设计方面的项目,包括ER图绘制,sql代写等典型的数据库设计工作。

database,Spatial Data Management,assignment代写,cs代写,作业代写

Overvew

The first assignment on this module involves the selection of a system (topic) of your choice, which you will then describe and for which you will create a documented UML E-R diagram (CONCEPTUAL). Your system may relate to your work, MSc degree, research or another area of interest but MUST include at least two entities requiring spatial data storage one of which must be a 3D entity (i.e. a spatial entity that has a volume1).

Additionally, it MUST include five spatially based functional requirements

and three requirements that need to join information from more than one entity to be answered.

NB: The system should NOT be similar to the examples we covered in class.

Part A – Topic Description

Once you have selected your system,

1. Write a system specification document (maximum length 1 page) for the system. This should include an overview of what the system will do, highlighting key entities in bold text (see Appendix 1 for an example).

2. Include a table listing the entities in your system and indicating whether they are spatial and 3D. This table should have the following format:

Entity # Entity Name Spatial 3D

1 Bus Stands Yes Yes

2 Road Network Yes No

3 Cleaning Staff No No

… … … …

Totals 10 2 1

3. Include a table with a list of 10 functional requirements that your system will meet. You MUST clearly show which requirements involve spatial queries and which involve joins. You should use 3 join operations (i.e. between two or more entities) and 5 different spatial operations – e.g. distance, area, volume, contains/within, intersects, neighbour, overlap, union, touch, perimeter calculation and so forth2. To demonstrate this you should submit a table using the following format:

1

In GIS, a 0-D entity is a point, a 1-D entity a line, a 2-D entity a polygon and a 3-D entity a polyhedron. Your 3D entity MUST enclose a volume – for example a shop, warehouse, office building, pipeline, hut and so forth would meet this criterion.

2

A full list of the operations available in PostGIS can be found here:

http://postgis.net/docs/reference.html#Operators (Sections 8.9 – 8.11).

Page 3 of 4

Requirement # Requirement Entity or

Entities

Required

Spatial

Query

Join

1 Which Bus Stands are along the A1 road and who is responsible for cleaning them

3D_Stands

Cleaning Staff

Yes Yes

2 What is the total surface area of all Bus

Stands

3D_Stands Yes

… … … … …

TOTALS 10 N/A 5 3

Part B – Conceptual Design

You are required to carry out the following task for your selected system:

Create a FULLY DOCUMENTED UML Entity-Relationship diagram for the database to be used with your proposed system. The diagram should be

CONCEPTUAL

The report describing your diagram should be structured as follows:

a. The E-R diagram.

b. Full Documentation for the E-R diagram, including

i. Descriptions for each entity and relationship, including cardinality of relationships and of attributes and identifiers

ii. Descriptions of any business rules and integrity constraints associated with the diagram

iii. Any derivations, information calculated from stored data or mathematical formulae that are required to fulfil the system brief

iv. Any assumptions made.

c. Appendix 1 – Rough notes and sketches made whilst drafting the

E-R diagram.

All of the above should be presented under separate headings and sub headings in the report.

Page 4 of 4

Some hints:

• The total assignment should be no longer than 8 pages, which does not include any appendices.

• When you have drafted your E-R diagram and report, be sure to doublecheck that the proposed system actually answers the questions that are being asked (meets the functional requirements).

• Remember that the report you produce is aimed at management – be careful to explain things very clearly and think about overall presentation of the report.

• The diagram MUST use the E-R diagram notation we used in class (i.e. UML).

• Your system should not be too complex – limit yourself to between 8 and 10 entities in total.

• You will be assessed on the quality of the documentation as well as on the

E-R diagram itself – remember that this document should be aimed at a management reader so be careful not to use terminology that may not be understood, and to write clearly.

• You should not use the examples we used in class or the example given below as any part of your E-R diagram. Marks will be deducted from both this assignment and assignment 2.

Appendix 1 – Example System Specification

London Transport Maintenance Ltd. is newly contracted to provide maintenance services for transportation infrastructure in different boroughs in London. They have identified a requirement for a system to track bus stop, bus shelter and bus stand maintenance to ensure that this are carried out to the correct specification in terms of their contract. The terms bus stop, bus shelter and bus stand are defined as follows:

• Bus stop – a simple stop showing details of routes and route time-tables, but not having any shelter.

• Bus shelter – a bus stop with an additional weather shelter.

• Bus stand – the start or end terminus of a route, with all features of a bus shelter and additional facilities for drivers (3D). Under the terms of their contract, they are required to inspect each bus stop, stand or shelter on a weekly basis, and perform monthly cleaning of any signage. They employ 20 cleaning staff to carry out this task, with each staff member being assigned to specific bus stops – i.e. one person will always maintain the same stops, stands or shelters. This team log any details of required repairs on the central system. Each repair is assigned a priority of normal, urgent or very urgent. The resolution of any issues reported by the inspection and cleaning teams is carried out by a maintenance team, which can be deployed to any stop, stand or shelter as required. There are 10 staff on the maintenance team.
